2003 - 2009 FORD 6.0 FICM Fuel Injection Control Module Repair


FORD 6.0 FICM (Fuel Injection Control Module) Repair

$199.95

  • This is a rebuild service for the FICM found in 2003 to 2009 Ford Super Duty trucks.

    Some 2003-2007 F-Super Duty, 2003-2005 Excursion and 2004-2010 E-Series vehicles equipped with a 6.0L engine may exhibit a runs rough, lacks power, hard start, no start concern with or without diagnostic trouble code (DTC) P0611 code or various injector circuit codes. This fault can also trigger low voltage on the injectors causing the following codes to be set, P0261, P0264, P0267, P0270, P0273, P0276, P0279 & P0282 Fuel economy is very poor and power loss is also common.

We repair and upgrade the root cause of the failure. Much more cost-effective compared to new Ford FICM and does NOT require reprogramming of the FICM. . One day turn around time, no need to ship it to the U.S. for repair or pay $700+ to get from the dealership.

Rebuilding your module will upgrade the circuitry so that it will never fail again vs. replacement with a used or brand new module that will only have the same problem in the future. It also alleviates the need to have FORD reprogram the new module. Reprogramming is not needed if it goes back in the original vehicle. If it is not the one that came out of your vehicle then it will require programming at FORD (which will cost about $120.00.)

We do not offer voltage upgrades, the Powerstroke FICM is already subjected to excessive heat and vibration. Upgrades increase heat and will degrade the internal circuits. This upgrade is for short term performance applications.


FICM Repair Service is for the following:


2003 - 2007 FORD F-250 6.0L SD Truck

2003 - 2007 FORD F-350 6.0L SD Truck

2003 FORD F-450 6.0L SD Truck

2003 FORD F-550 6.0L SD Truck

2003 - 2005 FORD Excursion 6.0L SUV

2003 - 2009 FORD Econoline 6.0L VAN
